Product Details
Place of Origin: CHINA
Brand Name: PASSION
Certification: ISO， CE
Model Number: 3/8"
Payment & Shipping Terms
Minimum Order Quantity: 1000m each size
Price: USD 0.6 M
Packaging Details: hoses are well packed by braided strips for export.
Delivery Time: 25 days on receipt of the deposit payment
Payment Terms: L/C, T/T, D/P, Western Union, MoneyGram
Supply Ability: 300000M / month
Material: |
Anti-static Rubber Material |
Application: |
Mainly Used For Circulating Petrol And Kerosene, Or The Oil Products With Contents Of Aromatic Substances Etc. |
Color: |
Black/red/blue/yellow |
Package: |
Well Packed In OPP Film And Braided Strap |
Size: |
1/4 Inch~1 Inch |
Temperature Resistance: |
-30c-to +100c |
Working Pressure: |
300psi |
Bursting Pressure: |
900psi |
Length: |
50m / Roll Or 100m/ Roll |
Printings: |
Accordingly To Client's Request |
MOQ: |
1000M Each Size |
Sea Port: |
Shanghai Port Or Ningbo Port |
Product Name: |
NBR Black Rubber Fuel Hose Fiber Braided 20 Bar Petrol Fuel Hose For Fuel Transfer |
Key Words: |
Anti-static Rubber Fuel Hose |
Material: |
Anti-static Rubber Material |
Application: |
Mainly Used For Circulating Petrol And Kerosene, Or The Oil Products With Contents Of Aromatic Substances Etc. |
Color: |
Black/red/blue/yellow |
Package: |
Well Packed In OPP Film And Braided Strap |
Size: |
1/4 Inch~1 Inch |
Temperature Resistance: |
-30c-to +100c |
Working Pressure: |
300psi |
Bursting Pressure: |
900psi |
Length: |
50m / Roll Or 100m/ Roll |
Printings: |
Accordingly To Client's Request |
MOQ: |
1000M Each Size |
Sea Port: |
Shanghai Port Or Ningbo Port |
Product Name: |
NBR Black Rubber Fuel Hose Fiber Braided 20 Bar Petrol Fuel Hose For Fuel Transfer |
Key Words: |
Anti-static Rubber Fuel Hose |
1" Anti-Static Gasoline Rubber Fuel Hose For Fuel Pumps
Construction - Tube: NBR
Reinforcement: High tensile polyester fiber braided.
Cover: NBR
Temperature: -30ºC to +100ºC
Color: Black, Red, Blue etc.
Application: Mainly used for circulating petrol and kerosene, or the oil products with contents of aromatic substances etc.
Standard length:
50m, 100m.
Specification:
|
Inner Diameter |
Outer Diameter | Working Pressure | Burst Pressure | Length | Measurement | Weight | |||
| inch | mm | mm | bar | psi | bar | psi | m | cbm/roll | kg/m |
| 3/16" | 5 | 11.5 | 20 | 300 | 60 | 900 | 100 | 0.028 | 0.15 |
| 1/4" | 6 | 13 | 20 | 300 | 60 | 900 | 100 | 0.031 | 0.17 |
| 5/16" | 8 | 15 | 20 | 300 | 60 | 900 | 100 | 0.0353 | 0.216 |
| 3/8" | 10 | 17 | 20 | 300 | 60 | 900 | 100 | 0.0442 | 0.24 |
| 1/2" | 12.7 | 22 | 20 | 300 | 60 | 900 | 100 | 0.0756 | 0.428 |
| 5/8" | 16 | 25 | 20 | 300 | 60 | 900 | 50 | 0.0329 | 0.40 |
| 3/4" | 19 | 29 | 20 | 300 | 60 | 900 | 50 | 0.0572 | 0.60 |
| 1" | 25 | 36 | 20 | 300 | 60 | 900 | 50 | 0.099 | 0.84 |
| 1-1/4" | 32 | 43 | 10 | 150 | 30 | 450 | 50 | 0.170 | 1.20 |
| 1-1/2" | 38 | 50 | 10 | 150 | 30 | 450 | 50 | 0.190 | 1.39 |
| 2" | 51 | 65 | 10 | 150 | 30 | 450 | 50 | 0.410 | 1.80 |
About PAISHUN
The factory covers a land of over 1.5 hectares, and the workshops occupy a surface of 7500 square meters. We own complete production lines of rubber mixing process, cold feeding
The factory covers a land of over 1.5 hectares, and the workshops occupy a surface of 7500 square meters. We own complete production lines of rubber mixing process, cold feeding material extrusion process, micro wave vulcanization process, and high speed braiding process, etc.
We produce mainly the industrial hoses like Air Hose, Water Hose, Oil Hose, Welding Hose, Hydraulic Hose and Assemblies. Paishun, being a rapidly growing enterprise focusing on the professional production of pure rubber hoses and braided rubber hoses, its yearly production capacity reaches 10 million meters.
