CLWB DN25 PTFE Convoluted Hose With 304 Stainless Steel Over Braided

CLWB DN25 PTFE Convoluted Hose With 304 Stainless Steel Over Braided

Braided PTFE Hose

PTFE Braided Hose

Place of Origin:

Zhejiang, China

Brand Name:



ISO 9001-2008, CE

Model Number:


Contact Us

Request A Quote
Product Details
Inner Tube:
Convoluted PTFE (DAIKIN)
Outer Layer:
304 Stainless Steel
Inner Diameter:
Outer Diameter:
Working Pressure:
38 Bar
Min. Bend Radius:
50~70m Roll
SAE 100R14
Main Market:
North America
Woven Strips, Pallet
Payment & Shipping Terms
Minimum Order Quantity
Packaging Details
woven strips wrapped / pallets
Delivery Time
15~20 days
Payment Terms
T/T, L/C, Western Union, MoneyGram
Supply Ability
100,000 meter per month
Product Description

CLWB DN25 PTFE Convoluted Hose With 304 Stainless Steel Over Braided




Excellent chemical resistance
Working temperature from -180°C to +260°C
FDA approved
Flame resistant - UL94V0
No stick
Low friction
Very good dielectric insulation properties


Construction: Tube: Domestic PTFE / The imported F-205 of Japan Daikin

                         Cover: AISI SS304 Braided


Temperature: -50℃ to +200℃ (Domestic Material)

                         -50℃ to +260℃ (Imported Material)


Application: Mainly used for conveying various chemicals, ships, automobiles, Marine industry machinery hydraulic system etc


Coil length: 40~80m (Random Length).


Standard: SAE100 R14


Connector: BSP, NPT, JIC etc


Item code Inner Diameter Outer Diameter Working Pressure Min. Bending Radius Approx. Weight
inch mm mm bar mm Kg/m
PS-8 5/16" 8 13.5 97 20.3 0.15
PS-10 3/8" 10 14.5 76 22.5 0.17
PS-12 1/2" 13 19.5 50 25.4 0.31
PS-16 5/8" 16 24.5 45 76.2 0.47
PS-19 3/4" 19 27.3 38 88.9 0.57
PS-25 1" 25 35 30 99 0.8
PS-32 1-1/4'' 32 33 25 112 0.98


Packing & Shipment


Normal Packing: opp film and woven strips wrapped

Customized Packing: Non-fumigation pallrt or Wooden reel


CLWB DN25 PTFE Convoluted Hose With 304 Stainless Steel Over Braided 0

Hose I.D




1-1/4'' ~ 2''





Competitive Advantage


1, 15 years manufacturing experience


2, Passion PTFE hose is made of virginal PTFE, with Excellent high temperature & corrosion resistance.


3, Hot sale in America, Canada, Germany, Mexico.


4, Free Sample / Hose assembly can be customized as per request


5, Small order is workable



Hangzhou Paishun Rubber and Plastic Co., Ltd established in 2007, is a rapid growing enterprise who integrate the production and marketing of rubber industrial hoses, rubber hydraulic hoses, and hydraulic hose fittings.

After 8 years effort and development, now we have become one of the leading rubber hose manufacturers and suppliers in China. We have been enjoying high reputation in rubber industrial hose and hydraulic hose market domestically and internationally.


Hangzhou Paishun Products Range:

Our factory focus on manufacturing Rubber industrial hoses, which include Rubber air hose , Rubber water hose , LPG gas hose , twin welding hose , rubber fuel hose.

Our stock-shared factory focus on manufacturing Rubber hydraulic hose , which includes SAE 100R1 , SAE 100R2 , SAE 100R7/ R8 , EN856 4SH , 4SP , SAE 100 R9 , R10 , R12 , SAE 100R14 Braided PTFE hose , Hydraulic hose fitting and ferrule ; Air conditioning hose ; Refrigerant charging hose .

We are very professional and have full experience in crimping fittings and quick release couplings on hoses. Such as rubber air hose assembly, contractor garden hose assembly, washing machine hose assembly, LPG hose assembly, hydraulic hose assembly, high pressure washer hose assembly, paint spray hose assembly, etc.

We are capable of supplying our products in various kinds of packaging according to customers' specific requirements.

Now our rubber hoses and hose assemblies are exported to USA, Canada, Italy, UK, Norway, Russia, Spain, Portugal, Denmark, Australia, Japan, Thailand, Sri Lanka, Peru, Brazil, Venezuela, South Africa etc, about 50 countries all over the world.

PASSION® Rubber hoses are approved by CE, SGS, TUV.


But Hangzhou Paishun have never stop going forward, in order to supply more rubber hoses to our customersand enlarge the production range, in 2012, together with our partner, we build another factory, which produce silicone auto rubber hoses in Jiangsu China.



CLWB DN25 PTFE Convoluted Hose With 304 Stainless Steel Over Braided 1

CLWB DN25 PTFE Convoluted Hose With 304 Stainless Steel Over Braided 2
