CE ISO 2398 ID 8mm industrial air hose / black rubber hose with Fiber Braided Reinforcement
Construction: Tube: NR& SBR synthetic rubber.
Reinforcement: High tensile polyester fiber braided.
Cover: NR & SBR synthetic rubber.
Temperature: -30℃ - +80℃
Color: Black, Red, Yellow, Blue, Green, Orange, etc.
Application: Mainly used for conveying of air, insert gas and water in mining, construction, engineering, shipbuilding, steel production etc.
Standard length: 50m, 100m.
Specification:
| Item code | Inner Diameter | Outer Diameter | Working Pressure | Burst Pressure | Length | Measurement | Weight | |||
| inch | mm | mm | bar | psi | bar | psi | m | cbm/roll | kg/m | |
| PRA-05 | 3/16" | 5 | 11.5 | 20 | 300 | 60 | 900 | 100 | 0.02 | 0.15 |
| PRA-06 | 1/4" | 6 | 13 | 20 | 300 | 60 | 900 | 100 | 0.025 | 0.17 |
| PRA-08 | 5/16" | 8 | 15 | 20 | 300 | 60 | 900 | 100 | 0.03 | 0.22 |
| PRA-10 | 3/8" | 10 | 17 | 20 | 300 | 60 | 900 | 100 | 0.04 | 0.26 |
| PRA-13 | 1/2" | 13 | 21 | 20 | 300 | 60 | 900 | 100 | 0.07 | 0.4 |
| PRA-16 | 5/8" | 16 | 24 | 20 | 300 | 60 | 900 | 50 | 0.06 | 0.45 |
| PRA-19 | 3/4" | 19 | 29 | 20 | 300 | 60 | 900 | 50 | 0.07 | 0.7 |
| PRA-25 | 1" (1b) | 25 | 36 | 12 | 180 | 36 | 540 | 50 | 0.09 | 0.85 |
| PRA-25-2 | 1" (2b) | 25 | 37 | 20 | 300 | 60 | 900 | 50 | 0.1 | 0.95 |
| PRA-32 | 1-1/4" | 32 | 44 | 10 | 150 | 30 | 450 | 50 | 0.16 | 1.4 |
| PRA-38 | 1-1/2" | 38 | 51 | 10 | 150 | 30 | 450 | 50 | 0.20 | 1.7 |
| PRA-51 | 2" | 51 | 65 | 10 | 150 | 30 | 450 | 20 | 0.20 | 2.2 |
Other Rubber Air Hose Surface: Cloth-Wrapped Surface, Groove Surface.
ISO Certificate:
Advantage:
PASSION Rubber Air hose is exported to Europe and North America for many years, produced according to ISO 2398, prodcution skill is advanced and with top high quality. Free sample can be offered to test.
