Name: Flexible PTFE Steam Hose for Large Industrial Iron Equipment
Brand: Hangzhou Paishun Rubber & Plastic Co., Ltd
SKU: SAE 100R14
Price: 15.29 USD
Availability: InStock

Home > Products > PTFE Braided Hose >

Flexible PTFE Steam Hose for Large Industrial Iron Equipment

Place of Origin:

China

Brand Name:

PASSIONCOHOSE

Certification:

ISO 9001-2015, CE, RoSH, REACH, FDA

Model Number:

SAE 100R14

Request A Quote

Flexible PTFE Steam Hose for Large Industrial Iron Equipment

Product Details

Model Number:

PTFE Hose, SAE 100R14

PTFE Hose Market:

North America, Europe, South America

Material:

PTFE

ID:

1/8" ~ 1"

Inner Tube:

Extruded Smooth PTFE

Cover:

SS 304 Single Wire Braid

Temperature:

-60℃ ~ +260℃

W.P:

179.5bar-48.8bar

B.P:

718bar-195bar

Customization Options:

Color, Length, End Fittings, Braid Material, Etc.

Packing:

Woven Strips, Pallet, Carton

Fittings:

OEM

Payment & Shipping Terms

Minimum Order Quantity

200M

Price

Negotiable

Packaging Details

Woven strips, pallet, carton, etc. We can also make package according to your requirements.

Delivery Time

within 25days after we have received the advanced payment

Payment Terms

L/C, , T/T, Western Union, MoneyGram

Supply Ability

300000M/Month

Flexible PTFE Steam Hose for Large Industrial Iron Equipment

Get Best Price

Video

Chemical Resistant PTFE Hose Assembly for Laboratory Fluid Transfer Systems

Get Best Price

Video

PTFE Hose Assembly with High Temperature Resistance and Chemical Resistant Properties for Anti-Static Applications

Get Best Price

Anti-Static PTFE Fuel Line Hose for Automotive Fuel Cell Systems

Get Best Price

Contact Now

Product Description

Smooth Bore PTFE Braided Hose for High Temperature Resistance

Description:

Smooth Bore Stainless Steel Braided PTFE Hoses

Inner tube: Smooth bore PTFE
Out Cover: Stainless Steel 304 or 316 Wire Braided
Temperature Range: -65℃ ~ +260℃
Standard: SAE 100R14
Feature: Excellent chemical resistance, high and low temperature resistance, excellent corrosion resistance, non-stick surface, flexibility, high purity, electrical insulation.

All braided PTFE hoses can increase Anti-Static performance with carbon treatment.

Part-number	Inner Diameter	I.D. (mm)	O.D. (mm)	Bending Radius (mm)	Min.W.P (bar)	Min. B.P. (bar)
PR14-02	1/8"	3.2	6.7	16	250	1000
PR14-03	3/16"	5.0	7.6	20	205	820
PR14-04	1/4"	6.5	9.4	27	188	752
PR14-05	5/16''	8.0	11.1	27	162	648
PR14-06	3/8''	10.0	13.2	33	130	520
PR14-08	1/2''	13.0	16.2	66	112	448
PR14-10	5/8"	16.3	19.4	150	80	320
PR14-12	3/4''	19.0	23.0	226	70	280
PR14-14	7/8"	22.5	26.2	245	60	240
PR14-16	1''	25.4	29.8	300	50	200

Application:

Industrial steam ironing machines
Large commercial steam irons
Industrial laundry and garment finishing equipment
Central steam supply systems for ironing lines
High temperature steam conveying systems in factories
