Place of Origin:
Zhejiang, China
Brand Name:
PASSIONCO HOSE
Certification:
CE, RoSH
Model Number:
PI-13
Description:
EPDM Rubber Hose is a versatile and durable hose designed for use in various industrial and agricultural applications. It is made from EPDM (Ethylene Propylene Diene Monomer), a type of synthetic rubber known for its excellent resistance to weather, ozone, heat, and chemicals.
Applications: It can handle air, water, light chemicals, and non-corrosive liquids, making it ideal for tasks like irrigation, construction, and even for use with air tools such as nailers and staplers
Features: The hose is highly resistant to abrasion and can tolerate both hot and cold water. It is also widely used for suction and delivery operations
Flexibility: Its flexibility and resistance to wear make it suitable for delivering fertilizers, acids, and general-purpose air and water tasks
Product Parameters:
| 1/2'' EPDM Rubber Insulated Hose | |
| Application | Suitable for use with high voltage resistance, it can transport hot water, hot air, or other inert gases. Widely used in the metallurgical industry, thermal induction furnace equipment. |
| Color | Black, Red, Green, or Customized |
| TEMP. Rang | -30ºC~100ºC / -30ºF~+210ºF |
| Inner Diameter | 1/2'' (12.8mm) |
| Certifications | CE & RoHS approved. |
| Material | High quality EPDM Synthetic Rubber |
| Reinforcement | High tensile polyester fiber braided |
| Length | 50/100 meters/roll |
| Specific Parameters | |||||||||||
| Part Number | I.D | O.D | Max W.P. | Min B.P. | Min Bend Radius | Weight | |||||
| NO. | inch | mm | inch | mm | psi | bar | psi | bar | inch | mm | kg/meter |
| PI-13 | 1/2 | 12.7 | 0.83 | 21.0 | 300 | 20 | 900 | 60 | 6.61 | 168 | 0.38 |
| PI-16 | 5/8 | 16.0 | 0.94 | 24.0 | 300 | 20 | 900 | 60 | 7.56 | 192 | 0.51 |
| PI-19 | 3/4 | 19.0 | 1.14 | 29.0 | 300 | 20 | 900 | 60 | 9.13 | 232 | 0.65 |
| PI-25 | 1 | 25.4 | 1.40 | 35.5 | 300 | 20 | 900 | 60 | 11.18 | 284 | 0.90 |
| PI-32 | 1-1/4 | 31.8 | 1.77 | 45.0 | 150 | 10 | 435 | 30 | 14.17 | 360 | 1.38 |
| PI-38 | 1-1/2 | 38.1 | 2.05 | 52.0 | 150 | 10 | 435 | 30 | 16.38 | 416 | 1.70 |
| PI-51 | 2 | 50.8 | 2.56 | 65.0 | 150 | 10 | 435 | 30 | 20.47 | 520 | 2.20 |
Applications:
For the transfer of air, water, light oils, and chemicals. The black nitrile tube is non-conductive, with minimum electrical resistance greater than 1 megohm per inch of length of hose at 1000 volts DC.
Advantages:
1. No bulge
2. Anti-kink
3. Non Conductive
4. High Flexibility
5. Wear Resistance
6. Aging Resistance
