Name: Red EPDM 1/2'' X 50FT with NPT Male Rubber Air Hose Assembly for Compressed Air
Brand: Hangzhou Paishun Rubber & Plastic Co., Ltd
SKU: PAA-1050
Price: 8.50 USD
Availability: InStock

Home > products > Rubber Air Hose >

Red EPDM 1/2'' X 50FT with NPT Male Rubber Air Hose Assembly for Compressed Air

Compressed Air Rubber Air Hose

1/2 Rubber Air Hose

NPT Male Rubber Air Hose

Place of Origin:

Zhejiang，China

Brand Name:

PASSIONCO HOSE

Certification:

CE, RoSH

Model Number:

PAA-1050

Request A Quote

Red EPDM 1/2'' X 50FT with NPT Male Rubber Air Hose Assembly for Compressed Air

Product Details

Material:

EPDM Synthetic Rubber

Inner Diameter:

1/4'' ~ 1''

Standard Length:

50FT, 100FT

Temp. Range:

-30℃~+90℃

Cover:

Smooth EPDM Synthetic Rubber

Certification:

RoHS, CE

Working Pressure:

20bar / 300psi

Bursting Pressure:

60bar / 900psi

Color Option:

Red, Blue, Black, Green, Etc.

Size:

1/4''X50ft

Highlight:

Compressed Air Rubber Air Hose

1/2 Rubber Air Hose

NPT Male Rubber Air Hose

Payment & Shipping Terms

Minimum Order Quantity

100pieces

Price

USD7.5~10.0 per piece

Packaging Details

Strong woven stripes wrapped

Delivery Time

30 working days

Payment Terms

L/C, T/T

Supply Ability

2000000 meters per month

Factory 3/4 Inch 19 mm Multi Use Wearing Resistant Quick Connect Oil Resistant Gas Tight NBR Rubber DIY Push Lock Hose

Get Best Price

Video

Factory Light Weight Flexible Anti-Weathering 1 inch Non Conductive EPDM Colling Hose

Get Best Price

Video

3/8'' Flame Resistant Breathing Air EPDM Rubber Hose 300psi for Human Breathing

Get Best Price

Video

Flame Resistant Black Anti-Aging Rubber Breathing Air Hose High Medium Pressure

Get Best Price

86-571-8102-3093

Contact Now

Product Description

Rubber Air Hose Assembly

Product Description:

Red EPDM 1/2'' X 50FT with NPT Male Rubber Air Hose Assembly for Compressed Air 0

Features:

1. Customized sizes.

2. Long life.

3. Aging resistance.
4. Joint is Firmly Buckled.
5. Customized LOGO.
6. Wear Resistance.
7. High Flexibility.
8. No Kinks.

Technical Parameters:

Factory Customized 1/2'' x 50FT with NPT Male Rubber Air Hose Assembly
Application	Industrial, Automotive, Construction, etc.
Color option	Red/Blue/Black/Green/Orange/Yellow etc.
TEMP. Rang	-30ºC ~ +90ºC
Inner Diameter	1/4'' ~ 1''
Certifications	CE & RoHS approved.
Fittings	NPT, BSP & other Male & Female thread connectors.
Inner Tube	NR & SBR Synthetic Rubber.
Outer Cover	SBR & EPDM Synthetic Rubber.

Specific Parameters
Part Number	I.D		O.D		Max W.P.		Min B.P.		Min Bend Raidus		Weight
NO.	inch	mm	inch	mm	psi	bar	psi	bar	inch	mm	kg/50ft
PAA-1050	3/8	10	0.67	17	300	20	900	60	6.69	170	4.40
PAA-1950	3/4	19	1.14	29	300	20	900	60	11.42	290	9.50

Applications:

Mainly used for conveying of air, inert gas, and water in mining, construction, engineering, shipbuilding, steel production, etc. Various sizes are suitable for machinery, tubes have good air tightness and pressure resistance. Excellent wear resistance, a good assistant for your life and work, improving work efficiency.

Red EPDM 1/2'' X 50FT with NPT Male Rubber Air Hose Assembly for Compressed Air 1
