Home > products > High Pressure Test Hose >

PASSIONHOSE DN3 1/8" 3.2mm ID 630Bar Ultra High Pressure Test Hose, 1600Bar Burst Pressure, PA Inner Tube Aramid Fiber Reinforced Polyurethane Cover, Air Charging Hose, 0.5m Extended Length

Place of Origin:

China

Brand Name:

PassionCO

Certification:

Request A Quote

Product Details

Inner Tube Material:

Reinforcement:

High Tensile Aramid Fiber

Outer Cover Material:

Smooth Polyurethane

Working Pressure Range:

-40℃~+120℃

Applications:

Mineral Oil, Water, Alcohol, Gasoline, Emulsions, Gases, Etc.

Safety Factor:

2.5 Times For Static Loads And 4 Times For Dynamic Loads

Working Pressure:

630 Bar

Payment & Shipping Terms

Minimum Order Quantity

200

Price

6.5USD/Piece

Packaging Details

Reel packaging, tray packaging,

Delivery Time

As your request

Payment Terms

L/C,T/T,D/P

Supply Ability

300000

DN2 3.2 mm Inner Diameter 630Bar Ultra High Pressure Test Hose 2000Bar Burst Pressure Air Charging Hose 0.5m Extended Length

Get Best Price

55CM Length both side M12*1.5 High Pressure Hose Assemblies Oil resistance

Get Best Price

Polyurethane High Pressure Test Hose for Test Application , blue High Pressure Water Hose

Get Best Price

Smooth Surface Ultra High Pressure Hose Safety For Injector Test Stands

Get Best Price

86-571-8102-3093

Contact Now

Product Description

Product Name: Test Hose
Inner Tube: PA
Reinforcement: High Tensile Aramid Fiber
Cover: Smooth Polyurethane
Colors: Black

Application & Performance Parameters

Application: Used for pressure detection at various points in hydraulic systems. As a pipeline for transmitting fluid media, it features light weight, wear resistance, high impact resistance, good elasticity, extremely low expansion rate, and ease of use.
Applicable Media: mineral oil, water, alcohol, gasoline, emulsions, gases, etc.
Temperature: -40°C ~ +120°C
Safety Factor: 2.5 times for static loads and 4 times for dynamic loads.

Part Number	I.D. (inch)	I.D.(mm)	Thickness(mm)	O.D.(mm)	W.P.(bar)	B.P.(bar)	Min. Bend Radius(mm)
DN3	1/8"	3.2	1.4	6	630	1300	30
