Place of Origin:
Jiangsu, China
Brand Name:
PassionCo
Certification:
ISO19031/AS1869
Model Number:
1/4"-1"
Product Overview
Push-On Hose | 300 PSI Performance | Versatile for Fuel, Air, and Various Fluids
Available Sizes: 1/4" to 1" | Tool-Free Fitting | Engineered for Demanding Use
Our Push-On Hose (sometimes called Push-Lock or No-Clamp Hose) is specially engineered for fast, secure installation without additional clamps. Rated for 300 PSI, it combines high flexibility with strong durability, making it a trusted choice across many industrial setups.
Quick Installation – No Extra Tools
Push the hose directly onto the fitting. No clamps, no hassle.
Oil-Resistant NBR Inner Layer
Built with Nitrile (NBR) rubber to withstand exposure to fuel, oil, and gases, meeting RMA Class A oil resistance standards.
Durable Outer Jacket
Constructed with CSM rubber, this cover resists abrasion, UV damage, and outdoor weathering.
Extreme Flexibility & Service Life
Tested for over 5 million bend cycles, perfect for applications involving repetitive movement.
Wide Temperature Endurance
Performs reliably from -30°C to +120°C for both indoor and outdoor tasks.
Enhanced Electrical Safety
Non-conductive design tested to resist up to 6000V, adding a layer of safety for electrical-sensitive operations.
Robotic Arm Pneumatics
Plastic Molding Equipment
Welding Gas Delivery Systems
General Fluid Handling (Air, Oil, Water, Coolants)
Coiling Reels and Cable Management Systems
This hose remains dependable in automotive production lines and complex automation processes.
Certifications: Meets ISO 19013 and AS 1869 standards
Safety Factor: 4:1 pressure ratio
Color Options: Standard in black, red, and blue; customization on request
Packaging: Export-ready with options for specific cut lengths or full pallet shipments
Component | Material | Properties |
---|---|---|
Tube | NBR Rubber | Resistant to oils and fuels |
Reinforcement | High-Tensile Fiber | Flexibility with strength |
Cover | CSM Rubber | Excellent UV and abrasion resistance |
Part No. | Size | I.D. (mm) | O.D. (mm) | Working Pressure | Burst Pressure | Min Bend Radius | Weight (kg/m) | Standard Length |
---|---|---|---|---|---|---|---|---|
PPL -06 | 1/4" | 6.4 | 13 | 300 PSI | 1200 PSI | 50 mm | 0.15 | 100 m |
PPL -08 | 5/16" | 7.9 | 15 | 300 PSI | 1200 PSI | 60 mm | 0.18 | 100 m |
PPL -10 | 3/8" | 9.5 | 17 | 300 PSI | 1200 PSI | 70 mm | 0.23 | 100 m |
PPL -13 | 1/2" | 12.7 | 21 | 300 PSI | 1200 PSI | 120 mm | 0.31 | 100 m |
PPL -16 | 5/8" | 15.9 | 24 | 300 PSI | 1200 PSI | 150 mm | 0.38 | 60 m |
PPL -19 | 3/4" | 19 | 28 | 300 PSI | 1200 PSI | 170 mm | 0.5 | 60 m |
PPL -25 | 1" | 25.4 | 36 | 300 PSI | 1200 PSI | 200 mm | 0.74 | 60 m |
If you’re searching for a hassle-free, long-life hose built for industrial pressure handling, this Push-On Hose fits the bill. Bulk purchasing and customized branding are welcome.
