Name: Low Permeation Heat Resistant Flexible J30R14 Fuel Hose
Brand: Hangzhou Paishun Rubber & Plastic Co., Ltd
SKU: 5/16"
Price: 14 USD
Availability: InStock

Home > products > Rubber Fuel Hose >

Low Permeation Heat Resistant Flexible J30R14 Fuel Hose

Place of Origin:

CHINA

Brand Name:

PASSION

Certification:

IATF16949, ISO9001:2015, CE, ROHS, REACH.

Model Number:

5/16"

Document:

SAEJ30R14 fuel hose.pdf

Request A Quote

Product Details

Working Pressure:

218 Psi

Burst Pressure:

725 Psi

Rubber Material:

FKM, ECO

Reinforcement:

Aramid Fiber

Barrier:

THV Barrier

Suggest Working Temperature:

Up To +130 °C (+266°F)

Resistant Working Temperature:

Up To +150 °C (+302°F)

Inner Diameter:

3/16" To 5/8"

Outer Diameter:

10.3 Mm To 23.6 Mm

Medium:

Gasoline, Ethanol Gasoline, Diesel, Bio-diesel

Payment & Shipping Terms

Minimum Order Quantity

1000

Price

14 USD/m

Packaging Details

well packed by high quality braided straps

Delivery Time

25-30days

Payment Terms

T/T

Supply Ability

50000 meters/month

SAE J30R7 Fuel Hose For Automotive And Motorcycle

Get Best Price

Video

Factory 1/4 Inch 6.3 mm Wearing Resistant Quick Connect Oil Resistant Gas Tight NBR Rubber DIY Multi-Purpose Hose

Get Best Price

Video

High Temperature SAE J30R7 Rubber Fuel Hose For Automotive Fuel Line

Get Best Price

Video

SAE 30R7 Fiber Braided Rubber Fuel Hose , High Temperature Fuel Line for Automotive

Get Best Price

86-571-8102-3093

Contact Now

Product Description

SAE J30R14 Fuel Hose Application:

Designed for fuel engines where low permeation is required.

For transferring gasoline, ethanol gasoline (E10, E15, E85), diesel and bio-diesel etc. in vehicles.

Product Description

Temperature Resistant: Up to +130 °C (+266°F) for long term use and +150 °C (+302°F) for short term use.
Standard Color: Black
Standard: SAE J30 R14 fuel line

Part Number	I.D.		O.D.	Max W.P.		Min B.P.
No.	in	mm	mm	psi	MPa.	psi	MPa
PJ30R14-03	3/16"	4.8	10.3	218	1.5	725	5.0
PJ30R14-04	1/4"	6.4	13.0	218	1.5	725	5.0
PJ30R14-05	5/16"	7.9	14.6	218	1.5	725	5.0
PJ30R14-06	3/8"	9.5	16.5	218	1.5	725	5.0
PJ30R14-08	1/2"	12.7	20.4	218	1.5	725	5.0
PJ30R14-10	5/8"	15.9	23.6	218	1.5	725	5.0

Low Permeation Heat Resistant Flexible J30R14 Fuel Hose 0

Low Permeation Heat Resistant Flexible J30R14 Fuel Hose 1
