Silver Hydraulic Hose Fitting , JIC Female 74 Degree Cone Seal ( 26711 )

Silver Hydraulic Hose Fitting , JIC Female 74 Degree Cone Seal ( 26711 )

hydraulic hose end fittings

hydraulics hoses and fittings

Place of Origin:

Zhejiang China

Brand Name:

PASSION

Certification:

ISO 9001-2008, CE

Model Number:

JIC FEMALE 26711

Contact Us
Request A Quote
Product Details
Part Number:
26711
Size Of Hose:
3/16” To 2”
Appearance:
Galvanized Zinc
Color:
Silver And Golden
Material:
Carbon Steel 45#
Standard:
Eaton
Technic:
Forge
Machine:
CNC
Highlight:

hydraulic hose end fittings

,

hydraulics hoses and fittings

Payment & Shipping Terms
Minimum Order Quantity
500pcs
Price
Negotiated
Packaging Details
Cartons and wooden cases
Delivery Time
Within 20 to 30 days after we receive advance payment
Payment Terms
T/T, L/C, Western Union, Paypal, MoneyGram
Supply Ability
60,000 pcs per month
Product Description



Silver Hydraulic Hose Fitting , JIC Female 74 Degree Cone Seal 26711




Applications:

Hydraulic Hose Fitting is widely used in the hydraulic and fluid conveying system of machinery,

oilfield, mine, building, transportation and other industries.



Standard: Yonghua

Technology: Hot forging

Material: carbon steel 45# or Stainless steel 304/316



Surface: zinc plated (trivalent chromium plating). The plating for hydraulic hose fitting is zinc with Cr +3.
It not only can reduce pollution obviously and save pollution treatment cost, but also can improve the quality of fitting.
It passes a 96 h salt spray test in accordance with ASTM B 117.







Specifications:



JIC FEMALE 74 DEGREE CONE SEAT



Catalogue of Straight JIC Female Fitting.pdf





                                Silver Hydraulic Hose Fitting , JIC Female 74 Degree Cone Seal ( 26711 ) 0  Silver Hydraulic Hose Fitting , JIC Female 74 Degree Cone Seal ( 26711 ) 1

                                              26711                                         26711-T


Part No. Thread E Hose Bore Dimensions
DN DASH A C S2
26711-04-03 7/16"x20 5 03 14.5 9 15
26711-04-04 7/16"x20 6 04 15 9 15
26711-05-04 1/2"x20 6 04 15.5 9.5 17
26711-05-05 1/2"x20 8 05 15.5 9.5 17
26711-05-06 1/2"x20 10 06 15.5 9.5 17
26711-06-04 9/16"x18 6 04 15.5 10.5 19
26711-06-05 9/16"x18 8 05 15.5 10.5 19
26711-06-06 9/16"x18 10 06 15.5 10.5 19
26711-06-08 9/16"x18 12 08 16 10.5 19
26711-08-06 3/4"x16 10 06 17.5 11 24
26711-08-08 3/4"x16 12 08 18 11 24
26711-08-10 3/4"x16 16 10 19.5 11 24
26711-10-08 7/8"x14 12 08 18.5 13 27
26711-10-10 7/8"x14 16 10 20 13 27
26711-10-12 7/8"x14 20 12 20 13 27
26711-12-08T 1.1/16"x12 12 08 19 15 32
26711-12-10 1.1/16"x12 16 10 21.5 15 32
26711-12-12 1.1/16"x12 20 12 21.5 15 32
26711-12-16 1.1/16"x12 25 16 23 15 32
26711-14-12 1.3/16"x12 20 12 21.5 15 36
26711-16-12T 1.5/16"x12 20 12 18.5 16 41
26711-16-16 1.5/16"x12 25 16 23 16 41
26711-16-20 1.5/16"x12 32 20 24 16 41
26711-20-16T 1.5/8"x12 25 16 23 17 50
26711-20-20W 1.5/8"x12 32 20 26 17 50
26711-24-20W 1.7/8"x12 32 20 26.5 20 55
26711-24-24W 1.7/8"x12 40 24 26.5 20 55
26711-32-20T 2.1/2"x12 32 20 27 23.5 75
26711-32-32T 2.1/2"x12 50 32 27 23.5 75



 Note: 1 for use with braided hoses, textile hoses and thermoplastic hoses, if use with spiral hoses, hose fitting series number is 26712-**-**.







Silver Hydraulic Hose Fitting , JIC Female 74 Degree Cone Seal ( 26711 ) 2




Other Hydraulic Hose Ferrule Fitting Products:


Silver Hydraulic Hose Fitting , JIC Female 74 Degree Cone Seal ( 26711 ) 3
Silver Hydraulic Hose Fitting , JIC Female 74 Degree Cone Seal ( 26711 ) 4




Production Flow:



Material of ferrule: carton steel 20#

Material of fitting: carton steel 45#

All of our machines are CNC machines



Silver Hydraulic Hose Fitting , JIC Female 74 Degree Cone Seal ( 26711 ) 5


Packgaing and Shipping:



Carton: 5 layers corrugated carton 24cm X 24cm X 16cm

Wooden Case: 110cm X 80cm X 75cm

Usually 42 corragetd cartons are packed in a wooden case.



Silver Hydraulic Hose Fitting , JIC Female 74 Degree Cone Seal ( 26711 ) 6
