Fiber Braided Flexible Rubber Hose , Rubber Fuel Hose For Diesel , Oil Fuel

Fiber Braided Flexible Rubber Hose , Rubber Fuel Hose For Diesel , Oil Fuel

  • High Light

    braided fuel hose

    ,

    fuel transfer hose

  • Material
    NBR Compound
  • Reinforcement Layer
    High Tensile Polyester Fiber Braided
  • Color
    Black, Blue, Red Etc
  • I.D Size
    5mm To 51mm
  • OD Size
    11.5mm To 65mm
  • Standard Length
    50m, 100m
  • Surface
    Smooth
  • Standard
    CE, ISO
  • Working Pressure
    20bar (300psi)
  • Burst Pressure
    60 Bar (300psi)
  • Packing
    Strong Transparent Plastic Film Wrapped
  • Temperature Range
    -30° To +100°C
  • Trademark
    PASSION Or OEM
  • Place of Origin
    Zhejiang China
  • Brand Name
    PASSION
  • Certification
    ISO 9001-2008, CE
  • Model Number
    I.D 3/16'' to 2''
  • Minimum Order Quantity
    2,000 m
  • Price
    Negotiable
  • Packaging Details
    Wrapped by transparent OPP film, pallet, color packing can be customized
  • Delivery Time
    30 days after received the advance payment
  • Payment Terms
    T/T, LC, Paypal or Western Union
  • Supply Ability
    400,000 m per month

Fiber Braided Flexible Rubber Hose , Rubber Fuel Hose For Diesel , Oil Fuel

Fiber Braided Flexible Rubber Hose , Rubber Fuel Hose For Diesel , Oil Fuel



Specifications:


Inner Diameter

Outer Diameter

Working Pressure

Burst Pressure

Length

Measurement

Weight

inch

mm

mm

bar

psi

bar

psi

m

cbm/roll

kg/m

3/16"

5

11.5

20

300

60

900

100

0.028

0.15

1/4"

6

13

20

300

60

900

100

0.031

0.17

5/16"

8

15

20

300

60

900

100

0.0353

0.216

3/8"

10

17

20

300

60

900

100

0.0442

0.24

1/2"

12.7

22

20

300

60

900

100

0.0756

0.428

5/8"

16

25

20

300

60

900

50

0.0329

0.40

3/4"

19

29

20

300

60

900

50

0.0572

0.60

1"

25

36

20

300

60

900

50

0.099

0.84

1-1/4"

32

43

10

150

30

450

50

0.170

1.20

1-1/2"

38

50

10

150

30

450

50

0.190

1.39

2"

51

65

10

150

30

450

50

0.410

1.80

 Fiber Braided Flexible Rubber Hose , Rubber Fuel Hose For Diesel , Oil Fuel 0






Description:

1, Construction:  Tube: NBR Synthetic Rubber
                           Reinforcement: High tensile polyester fiber braided.
                           Cover: NBR Synthetic Rubber



2, Appearance:  Smooth finish, Black, Red, Blue etc


3, Applicable temperature: -30℃ to +100℃


4, Bend radius: 10 times of proper diameter dimension


5, Package:  Common packed by OPP transparent film.

The pallet and woven bag packing are available, the color sticker can be offerd,

but shall be charged additionally.


6, Trademark: PASSION, OEM is available


7, Property: Good oil resistance and excellent flexibility. Without craze crack or fracture  after 180°bending over or doubling


8, Certificates: CE, SGS


9, Main market: Middle East, Europe and America


10: Joint Connection: Customized as your request



Applications:

It is applied to circulating diesel, biodiesel, hydraulic oil, machinery oils and lubricating oil, or the oil products with the contents of aromatic substances not more than 30%; both the inner layer and protective layer of rubber hose of this grade are oil corrosion resistant and insulated.



Competitive Advantage:

Hangzhou Paishun Rubber And Plastic Co., Ltd, a leading rubber hose manufacturer in the east of China. 8 years manufacturing experience, 50 sets of braiders and 3 production lines.

Paishun has a strict quality inspection team, every shipment would be tested before shipment.


Free sample can be offered, we are happy to customize as your request.





Cooperative Brands:

WELDMAN, Max Weld, SAEFLEX. REDI-WELD

Paishun's Slogan:

PASSION FOR HOSE! PASSION FOR YOU!
